ABB Freelance 2000 - E 2.2.1 Enhancements to Parameter Definition Mask 2 in Signal Sequence Log N

Section E Logs
E-10
Record event from
local resource D-OS Events on the operator station are logged. These include events such as
switching operations and operator actions.
Filter Activates logging of events such as messages and faults on the corre-
sponding resource.
Connection Indicator showing that a connection is configured to the corresponding
operator station.
Filter Either all configured stations or only connected stations are included in the
events selection list.
Areas Messages from the selected areas are set in the signal sequence log.
Type of messages Configures which messages are to be recorded in the log: process mes-
sages, system messages and sequence of events.
E 2.2.1 Enhancements to parameter definition mask 2 in signal sequence log N
Unlike signal sequence log 1, data of signal sequence log N are not printed continuously.
Hence the parameter definition mask 2 differs in the following points:
The following virtual keys are to choose additionally:
Print
Automatic Printing takes place automatically after completing the logging.
Delete log files
Printed files only Only printed log files can be deleted manually.
