Section E Logs
E-20
Parameters trigger
The time of acquisition of the variables to be parameterized is based on the configured signal
situation on the disturbance course log acquisition module.
See Engineering Reference Manual, Functions and Function Blocks, Acquisition Blocks.
Trig.:
Name Name of the variable that triggers the switch on the disturbance course log
acquisition module. This name appears for information only and is included
in the printout. It is not evaluated further as the acquisition modules trig in-
put bears this responsibility. Even if the trigger is not actuated by a variable,
a text must be entered here.
Text Text that will be output as a comment after the name of the trigger variable.
Parameters variable specification
Up to six variables can be configured for data acquisition for the disturbance course log. The
number of variables is limited by the inputs in the disturbance course acquisition module.
V1 ... V6
Name Name of the variable on the process station.
Text Text output on logging the variable.
Format The format is necessary for output of variables in the log. See Engineering
Manual, Operator Station, Grafic Display, Alphanumeric Display, Se-
lect and create own formats.
Dimension The dimension assigned to the variable. The dimension is output with the
variable value during logging.
No plausibility check is performed on name, text or dimension as the variables are config-
ured permanently with the acquisition module. Details included here serve only to provide
information and are included in the log when it is printed out.
E 3.4 File transfer tab - Disturbance course log
This parameter definition mask corresponds to the parameter definition mask of the Signal
Sequence Log, see page E-12.
