Section D Graphic Display
D-52
Examples of user defined data formats:
Data type Format Example
REAL
[+|-|]f.ff...{E[+|-]ee} 3.141E+00, 3.0, -4.2, +6.2E-05
INT, UINT, DINT, UDINT
[+|-]fff... 35, 4000, +500
BYTE, WORD, DWORD 0f 07
TIME see fixed data format
DT see fixed data format
STRING types s:L{,S}:Z:I:T
High, Low
Control characters for use with strings:
. Number of displayed characters. Default: all
S: Position of the first character to be displayed. Default: 0
Character 1 occupies position 0.
Z: Line to be displayed, for all lines enter 0. Default: 0
I: Display of control characters and margin delimiters;
Options y or n. Default: y
T: Interpret tab signs, options y or n. Default: n
Control characters:
$R Carriage Return (CR),
$N Line Feed (LF),
$L Carriage Return and Line Feed ($R$N),
$T Tab,
$ff Hex-coded ASCII character (e.g. '$41' for 'A'),
$' Apostrophe (‘)
$$ Dollar sign ($).
