Section E Logs
E-8
Long text A Long text can be assigned to the signal sequence log. Up to 30 charac-
ters can be entered.
The short and long texts are output with the project documentation. In addi-
tion these texts can be configured for the header and footer of the
printed log.
Start/Stop
Automatic Logging is automatically started by starting DigiVis.
Event controlled Logging is started and stopped by an event.
Tag name of event
function block Name of event starting logging, Engineering Reference Manual, Functi-
ons and Function Blocks, Monitoring Function Blocks. Press the func-
tionkeyF2tobringupaselectionlist.
Manual The operator can start and stop logging on the operator station. This refers
only to the log previously selected on the operator station.
Filing
in .. files the number of log files are fixed, which are created on DigiVis PC. The
value must be between 1 and 400.
named the name of the log file, which is filed on DigiVis PC hard disk. You can ac-
cept the suggested name or give another.
With max. runtime
... per file The recording period per log file can be defined with this field. Entries are
made in the IEC 1131-3 format. The value range is between 0 and 2147483
sec.
Example:
T#2147483s or T#24d20h31m23s
but not more than
... events The value must be between 3 and 32767. Default 1000 events.
Disk space
requirements
for this log: The size which log files can attain is displayed in this field. This amount of
storage should be available on DigiVis PC.
