ABB IRB 2600 Series User Manual

Tightening torque (Nm)
Class 12.9, lubricated
i
Tightening torque (Nm)
Class 10.9, lubricated
i
Dimension
7055M10
12096M12
280235M16
550460M20
950790M24
i
Lubricated with Molycote 1000, Gleitmo 603 or equivalent
Water and air connectors
The following table specifies the recommended standard tightening torque for
water and air connectors when one or both connectors are made of brass.
Note
A special torque specified in the repair, maintenance or installation procedure
overrides the standard torque.
Tightening torque Nm -
Max.
Tightening torque Nm -
Min.
Tightening torque Nm -
Nominal
Dimension
158121/8
2010151/4
2515203/8
5030401/2
9055703/4
Product manual - IRB 2600 439
3HAC035504-001 Revision: Q
© Copyright 2009-2018 ABB. All rights reserved.
8 Reference information
8.4 Screw joints
Continued

ABB IRB 2600 Series Specifications

General

Number of Axes	6
Robot Control	IRC5
Mounting	wall
Protection	IP67
Max Speed	Axis 1: 180°/s
Reach	1.65 m / 1.85 m
