5.3.5 Replacing the process connectors
Location
The illustration shows the location of the process connectors in the controller.
xx1800000737
Note
To confirm whether this unit is available in your controller, see chapter Overview
of the controller on page 38.
If this unit is not available in your controller, ignore the related procedure to this
unit when you do any maintenance or repair work.
Required spare parts
Note
The spare part numbers that are listed in the table can be out of date. See the
latest spare parts of the OmniCore C30 via myABB Business Portal,
www.abb.com/myABB.
NoteArticle numberSpare part
3HAC063601-001Harness DeviceNet/Harness 24V
ext. cover plate
DSQC10043HAC062150-001Harness DeviceNet connection
Mating CONN for IP20 DeviceNet
connector
3HAC064901-001Connector assembly Single-row
female
Continues on next page
Product manual - OmniCore C30 455
3HAC060860-001 Revision: P
© Copyright 2019-2022 ABB. All rights reserved.
5 Repair
5.3.5 Replacing the process connectors
