3.7.4 Installing the power supply optional device and the harness 24 V extension
Location
The illustration shows the location of the power supply optional device in the
controller.
A
B
xx1800000035
Power supply baselineA
Power supply optionalB
Harness 24 V extension device is an option of IP20 power outlet connector.
The illustration shows the location of the harness 24 V extension in the controller.
xx1800000740
Continues on next page
152 Product manual - OmniCore C30
3HAC060860-001 Revision: P
