Note
Any local standards and regulations concerning insulation and area must always
be complied with.
AC current in CP/CS
For specific applications where the correct cable dimensioning can depend on the
relationship between the period of the duty cycle and the thermal time constant of
the cable (for example, starting against high-inertia load, intermittent duty), the
cable manufacturer can provide information.
Country specific norms have to be included.
The wire is not dimensioned to take care of starting motors or transformers.
The following table shows how much AC current can be suppled with a specific
temperature, and the wire size.
AC currentWire size (mm
2
//AWG)
52°C//125.6F50°C//122F45°C//113F40°C//104F
3.23.74.14.5Single wire 0.2//24
2.63.03.33.6Multi wire 2 pair 0.2//24
2.12.42.72.9Multi wire 4 pair 0.2//24
1.82.12.32.6Multi wire 6 pair 0.2//24
1.61.82.02.3Multi wire 9 pair 0.2//24
5.66.57.27.9Single wire 0.5//20
4.55.25.86.3Multi wire 2 pair 0.5//20
3.64.24.75.1Multi wire 4 pair 0.5//20
3.23.74.14.5Multi wire 6 pair 0.5//20
2.83.23.64.0Multi wire 9 pair 0.5//20
6.77.88.69.5Single wire 0.75//18
5.46.26.97.6Multi wire 2 pair 0.75//18
4.45.15.66.2Multi wire 4 pair 0.75//18
3.84.44.95.4Multi wire 6 pair 0.75//18
3.43.94.34.8Multi wire 9 pair 0.75//18
7.89.010.011.0Single wire 1.0//17
6.27.28.08.8Multi wire 2 pair 1.0//17
5.15.96.57.2Multi wire 4 pair 1.0//17
4.55.15.76.3Multi wire 6 pair 1.0//17
3.94.55.05.5Multi wire 9 pair 1.0//17
5.67.17.88.60.75//18 three phase
6.78.49.410.31.0//17 three phase
Continues on next page
86 Product manual - OmniCore C30
3HAC060860-001 Revision: P
© Copyright 2019-2022 ABB. All rights reserved.
3 Installation and commissioning
3.5.2 Connecting cables to the controller
Continued
