102 Parameters
165 SCADA data in
Inverter SCADA data in.
165.01
...
165.15
Data in 1
...
Data in 15
Inverter SCADA interface data in. -/ Real
0...65535 1 = 1
165.50
...
165.56
Data in 50
...
Data in 56
Inverter SCADA interface data in. -/ Real
. 0...65535 1 = 1
166 SCADA data out
Inverter SCADA data out.
166.01
...
166.11
Data out 1
...
Data out 11
Inverter SCADA interface data out. -/ Real
0...65535 1 = 1
166.50
...
166.160
Data out 50
...
Data out 160
Inverter SCADA interface data out. -/ Real
0...65535 1 = 1
173 Inverter status
Inverter control and status words.
All parameters in this group are read-only unless
otherwise specified.
173.01 Main status word Main status word of the inverter. See Operational
description on page 14.
0b0000/
Bit list
b0: Ready Ready to operate
b1: Faulted Faulted
b2: Warning Warning active
b3: MPPT enabled MPPT enabled
b4: Grid stable Grid stable
b5: DC voltage within
range
DC voltage is within the range
b6: Inhibits Start is inhibited
b7: Reduced run Reduced run active
b8: Redundant run Redundant run active
b9: Q-compensation Q-compensation or night Q production is active
b10: Limited Active or reactive power is limited
b11: Grid connected Grid is connected
b12...b15: Reserved -
173.02 Inverter main state Shows main state of the inverter. Initialize/ List
Initialize Initializing 0
Service mode Service mode 1
Commissioning mode Commissioning mode 2
Disconnected Disconnected from the grid 3
Disconnecting Running disconnect routines 4
Connecting Running connect routines 5
Connected Connected to grid 6
No. Name/Value Description Def/
FbEq16/32
