Parameters 143
24 DC inputs 5
Not selected 1
Selected 2
Not selected 1
Selected 2
Not selected 1
Selected 2
Not selected 1
Selected 2
Not selected 1
Selected 2
Not selected 1
Selected 2
Not selected 1
Selected 2
Not selected 1
Selected 2
Not selected 1
Selected 2
Not selected 1
Selected 2
Old (1xD0573)
New (2xD0571)
208 DC input monitor
DC input voltage monitoring related parameter group.
208.01 Input voltage Shows DC input voltage.
This parameter is read-only.
-/ Real
- 1 = 1 V
208.03 Input power Shows DC input power.
This parameter is read-only.
-/ Real
0.0...10000.0 kW Power in kilowatts. 1 = 1 kW/
10 = 1 kW
208.04 Input current Shows input current of the inverter.
This parameter is read-only.
0 / Real
-4000...4000 A Power module input current. 1 = 1 A
208.09 Input current monitoring Enables DC current monitoring function. Enabled/ List
Disabled DC current monitoring disabled. 0
Enabled DC current monitoring enabled. 1
208.12 Reverse current limit Defines reverse current limit. A smaller current value is
interpreted as reverse current.
-100.0 A/
Real
-500.0...100.0 A Reverse current limit. 10 = 1 A
208.13 Reverse current delay Defines duration for which DC input current has to be
more negative than the limit at which a trip is triggered.
2 s/ Real
0...2000 s Reverse time limit 1 = 1 s
No. Name/Value Description Def/
FbEq16/32
