64 Parameters
112 Standard AI
Configuration of standard analog inputs.
112.11 AI1 actual value Shows value of analog input AI1 in V or mA.
This parameter is read-only.
-/ Real
-22.000...
22.000 mA or V
Value of analog input AI1. 1000 = 1 mA
or V
112.21 AI2 actual value Shows value of analog input AI2 in V or mA.
This parameter is read-only.
-/ Real
-22.000...22.000 mA Value of analog input AI2. 1000 = 1 mA
or V
113 Standard AO
Analog outputs configuration.
113.11 AO1 actual value Shows value of analog output AO1 in mA.
This parameter is read-only.
-/ Real
0.000 … 22.000 mA Value of AO1. 1000 = 1 mA
113.21 AO2 actual value Shows value of analog output AO2 in mA.
This parameter is read-only.
-/ Real
0.000 … 22.000 mA Value of AO2. 1000 = 1 mA
114 Extension I/O
module 1
Configuration of I/O extension module 1.
Note: Contents of this parameter group vary according
to the selected I/O extension module type.
114.01 Module 1 type Activates and specifies the type of I/O extension
module 1.
None/ List
None Inactive. 0
FIO-01 FIO-01. 1
FIO-11 FIO-11. 2
FAIO-01 FAIO-01. 3
114.02 Module 1 location Specifies node number (1...3) on the control unit into
which the I/O extension module is installed. (Node 1 =
slot 1, node 2 = slot 2, node 3 = slot 3). Alternatively,
specifies the node ID of the slot on an FEA-0x extension
adapter.
Slot 1/ List
Not selected 0
Slot 1 1
Slot 2 2
Slot 3 3
114.03 Module 1 status Shows status of I/O extension module 1.
This parameter is read-only.
No option/
List
No option No module detected in the specified slot. 0
FIO-01 An FIO-01 module is detected and is active. 1
FEN-01 An FEN-01 module is detected and is active. 2
FEN-11 An FEN-11 module is detected and is active. 3
FEN-21 An FEN-21 module is detected and is active. 4
FIO-11 An FIO-11 module is detected and is active. 5
FEN-31 An FEN-31 module is detected and is active. 6
FAIO-01 An FAIO-01 module is detected and is active. 7
No. Name/Value Description Def/
FbEq16/32
