Parameters 149
211.71 Sensor fail status Shows temperature sensor fail status of the following
measurements:
• control cabinet
• main air channel
• LCL cabinet
• AC cabinet.
0b0000/
Bit list
b0: Control cabinet Sensor failure status of the control cabinet temperature
measurement.
b1: Main air channel Sensor failure status of main air channel temperature
measurement.
b2: LCL cabinet M1 Sensor failure status of the module 1 LCL cabinet
temperature.
b3: LCL cabinet M2 Sensor failure status of the module 2 LCL cabinet
temperature.
b4...b5 Reserved
b6: AC cabinet M1 Sensor failure status of the module 1 AC cabinet
temperature.
b7: AC cabinet M2 Sensor failure status of the module 2 AC cabinet
temperature.
b8 … b15 Reserved
211.90 Highest IGBT
temperature
Shows highest IGBT temperature. 1.0 °C/ Real
-100.0 … 200.0 °C 10 = 1 °C
213 Wake-up monitor
Parameters for wake-up/sleep monitor and state
machine.
213.02 Wake-up state Shows wake-up monitor state for debugging.
This parameter is read-only.
Initialize/ List
Initialize Inverter is initializing or not yet ready for operation. 0
First start Inverter waits for DC voltage to settle between limits. 1
Disconnected wake After inverter has completed sleep, it checks when input
voltage is suitable for grid connection.
2
Connected wake Inverter is connected to grid. It monitors the power level
to be high enough and the wake timer has expired.
3
Low power Inverter is operating, but power is lower than the
minimum limit.
4
Reconnect When power is too low for a long time, a reconnection is
not allowed for the duration of the set time limit.
5
Reconnect open DC When power is too low for long time and DC voltage
goes too low, the DC contactors are opened.
6
Connected sleep Inverter operated normally. Wake-up is completed and
inverter is checking sleep conditions.
7
Fault recover A fault has occurred and the inverter used the first start
limits and tries to connect back.
8
Going to sleep Power of the inverter drops below going to sleep limit. 9
Disconnected sleep Inverter shuts down and waits for the cool down period,
until a wake-up can be tried.
10
Wakeup count over Reconnection was attempted number of times. A cool
down for many hours will be done before further
reconnection.
11
No. Name/Value Description Def/
FbEq16/32
