Parameters 59
Summary of parameter groups
Group Contents Page
101 Actual values Basic signals for monitoring the inverter. 61
104 Warnings and faults Information on warnings and faults. 62
107 System info Inverter hardware and firmware information. 63
110 Standard DI, RO Configuration of digital inputs and relay outputs. 63
111 Standard DIO, FI, FO Configuration of digital input/outputs and frequency
input/outputs.
63
112 Standard AI Configuration of standard analog inputs. 64
113 Standard AO Analog outputs configuration. 64
114 Extension I/O module 1 Configuration of I/O extension module 1. 64
115 Extension I/O module 2 Configuration of I/O extension module 2. 65
116 Extension I/O module 3 Configuration of I/O extension module 3. 65
124 Reactive power reference Settings for reactive power reference selection, limitation and
ramping.
66
125 FRT support curve Settings for FRT support curve. 70
126 FRT tripping curve Settings for FRT tripping curve. 73
130 Limits Operation limits of the inverter. 76
135 Grid monitoring Settings for grid monitoring. 81
150 FBA Fieldbus adapter communication configuration. 88
151 FBA A settings Fieldbus adapter A configuration. 94
152 FBA A data in Selection of data to be transferred from Inverter to fieldbus
controller through fieldbus adapter A.
97
153 FBA A data out Selection of data to be transferred from fieldbus controller to
inverter through fieldbus adapter A.
98
154 FBA B settings Fieldbus adapter B configuration. 98
155 FBA B data in Selection of data to be transferred from the inverter to fieldbus
controller through fieldbus adapter B.
100
156 FBA B data out Selection of data to be transferred from fieldbus controller to the
inverter through fieldbus adapter B.
100
164 SCADA configuration SCADA configuration. 101
165 SCADA data in Inverter SCADA data in. 102
166 SCADA data out Inverter SCADA data out. 102
173 Inverter status Inverter control and status words. 102
174 DC input current monitor DC input current monitor. 106
176 Customer IOs Customer inputs and outputs. 112
177 MV Station Medium voltage station parameters including MV transformer
and MV switchgear.
115
178 MPPT settings MPPT settings. 124
