Parameters 115
Spare DI8 9
Spare DI9 10
Spare DI10 11
Spare DI11 12
Spare DI12 13
Other See Terms and abbreviations on page 57. -
176.32 External fault 3 action Selects action type in the event of customer IO external
fault 3.
No action/
List
No action 0
Delayed warning 1
Warning and delayed
fault
2
Delayed fault 3
176.33 External fault 3 action
delay
Defines delay time for customer IO external fault 3
action.
0 s/ List
0...3600 s 1 = 1 s
176.34 External fault 3 failure
logic
Selects customer IO external fault 3 failure logic as
active high or active low.
Active High/
List
Active Low 0
Active High 1
177 MV Station
Medium voltage station parameters including MV
transformer and MV switchgear.
177.11 MV temperature alarm
source
Selects source for medium voltage transformer
overtemperature alarm.
See also Digital inputs on page 50.
Off/ List
Off 0
On 1
Digital input X20.1 2
Digital input X20.2 3
Digital input X20.3 4
Digital input X20.4 5
Digital input X20.5 6
Digital input X20.6 7
Digital input X20.7 8
Spare DI8 9
Spare DI9 10
Spare DI10 11
Spare DI11 12
Spare DI12 13
Other See Terms and abbreviations on page 57. -
177.12 Transformer
temperature alarm
action
Selects medium voltage transformer overtemperature
alarm action.
No action/
List
No action 0
Delayed warning 1
No. Name/Value Description Def/
FbEq16/32
