114 Parameters
176.24 External fault 1 failure
logic
Selects customer IO external fault 1 failure logic as
active high or active low.
Active High/
List
Active Low 0
Active High 1
176.26 External fault 2 source Selects source for customer IO external fault 2 signal.
See also MV station monitoring and control on page 50.
Off/ List
Off 0
On 1
Digital input X20.1 2
Digital input X20.2 3
Digital input X20.3 4
Digital input X20.4 5
Digital input X20.5 6
Digital input X20.6 7
Digital input X20.7 8
Spare DI8 9
Spare DI9 10
Spare DI10 11
Spare DI11 12
Spare DI12 13
Other See Terms and abbreviations on page 57. -
176.27 External fault 2 action Selects action type in the event of customer IO external
fault 2.
No action/
List
No action 0
Delayed warning 1
Warning and delayed
fault
2
Delayed fault 3
176.28 External fault 2 action
delay
Defines delay time for customer IO external fault 2
action.
0 s/ List
0...3600 s 1 = 1 s
176.29 External fault 2 failure
logic
Selects customer IO external fault 2 failure logic as
active high or active low.
Active High/
List
Active Low 0
Active High 1
176.31 External fault 3 source Selects source for customer IO external fault 3 signal.
See also MV station monitoring and control on page 50.
Off/ List
Off 0
On 1
Digital input X20.1 2
Digital input X20.2 3
Digital input X20.3 4
Digital input X20.4 5
Digital input X20.5 6
Digital input X20.6 7
Digital input X20.7 8
No. Name/Value Description Def/
FbEq16/32
