Parameters 135
0 … 20000 rpm 1 = 1 rpm
202.70 Main fans fail status Shows main air channel fans fail status.
This parameter is read-only.
0b0000/
Bit list
b0 M1 Fan 1 Failed status of main air channel fan 1, module 1.
b1 M1 Fan 2 Failed status of main air channel fan 2, module 1.
b2 M1 Fan 3 Failed status of main air channel fan 3, module 1.
b3 M1 Fan 4 Failed status of main air channel fan 4, module 1.
b4 M2 Fan 1 Failed status of main air channel fan 1, module 2.
b5 M2 Fan 2 Failed status of main air channel fan 2, module 2.
b6 M2 Fan 3 Failed status of main air channel fan 3, module 2.
b7 M2 Fan 4 Failed status of main air channel fan 4, module 2.
b8...b15 Reserved
202.71 LCL fans fail status Shows LCL fans fail status.
This parameter is read-only.
0b0000/
Bit list
b0 M1 Fan 1 Failed status of LCL fan 1, module 1.
b1 M1 Fan 2 Failed status of LCL fan 2, module 1.
b2 M2 Fan 1 Failed status of LCL fan 1, module 2.
b3 M2 Fan 2 Failed status of LCL fan 2, module 2.
b4 … 15 Reserved
202.72 Chained feedback fans
fail status
Shows chained feedback fans fail status.
This parameter is read-only.
0b0000/
Bit list
b0 M1 Fans Failed status of fans with chained status feedback,
module 1.
b1 M2 Fans Failed status of fans with chained status feedback,
module 2.
b2 … 15 Reserved
204 PLC Extension
Inputs
PLC extension inputs.
204.01 PLC digital Inputs 1 PLC CPU unit PM564 digital inputs 0x0000/
Bit list
b0: Main circuit SPD
status
b1: Smoke detector
b2: Digital input X20.1
b3: Digital input X20.2
b4: Digital input X20.3
b5: Digital input X20.4
b6 … b15 Reserved
204.02 M1 DC current
measurement
Defines raw data for total DC current measurement of
power module 1.
-/ Real
0...65535 1 = 1
204.03 M2 DC current
measurement
Defines raw data for total DC current measurement of
power module 2.
-/ Real
0...65535 1 = 1
No. Name/Value Description Def/
FbEq16/32
