136 Parameters
204.04 PLC digital inputs 2 PLC I/O unit DX571 # 1 digital inputs 0x0000/
Bit list
b0: M1 DC switch status
b1: M1 AC switch
feedback
b2: M1 LCL overheating
status
b3: M1 AC contactor
status
b4: M1 DC contactor
status
b5: M1 48 Vdc status
b6: M1 48 Vdc buffer
status
b7: M1 Cabinet fan
status
b8: M1 AC door status
b9: M1 DC door status
b10: M1 DC input fuses
status
b11: M1 AC breaker
tripped
b12: Spare DI8
b13: Digital input X20.5
b14: Digital input X20.6
b15: Digital input X20.7
204.05 PLC digital inputs 3 PLC I/O unit DX571 # 2 digital inputs. 0x0000/
Bit list
b0: M2 DC switch status
b1: M2 AC switch
feedback
b2: M2 LCL overheating
status
b3: M2 AC contactor
status
b4: M2 DC contactor
status
b5: M2 48 Vdc status
b6: M2 48 Vdc buffer
status
b7: M2 Cabinet fan
status
b8: M2 AC door status
b9: M2 DC door status
b10: M2 DC input fuses
status
b11: M2 AC breaker
tripped
b12: Spare DI7
No. Name/Value Description Def/
FbEq16/32
