Parameters 81
130.101 Priority Defines priority of active current or reactive current
when current must be limited.
Active
current/
List
Active current 0
Reactive current 1
135 Grid monitoring
Settings for grid monitoring.
135.01 Grid code Selects grid code. Changing this value sets default
and/or mandatory values for all other grid parameters.
Not selected/
List
Not selected Grid code not selected 0
Custom 6
Dubai 10
Egypt 11
ERCOT 12
Germany 16
HECO 17
IEEE 1547 18
Italy 20
Jordan IRR-TIC 21
Jordan IRR-DCC-MV 22
Romania 25
Rule 21 26
South Africa 28
Turkey 37
WECC 39
135.02 Nominal LL voltage Defines nominal line-to-line voltage. 400 V/ Real
100...1000 V Nominal line-to-line voltage. 1 = 1 V
135.04 Nominal frequency Selects nominal grid frequency. 50 Hz/ List
50 Hz 0
60 Hz 1
135.10 Initial connection delay Defines delay time for initial grid connection after power
up or inverter is enabled.
5 s/ Real
5...300 s Delay time for initial grid connection. 1 = 1 s
135.11 Reconnection delay Defines delay time for reconnection due to grid
monitoring.
60 s/ Real
3...300 s Reconnection delay time. 1 = 1 s
135.12 Quick disturbance limit Enables quick reconnection delay when value is larger
than zero and allows quick reconnection if the grid
returns to normal condition within the time limit.
0 s/ Real
0...300 s Quick reconnection limit. 1 = 1 s
135.13 Quick reconnection
delay
Defines delay time for quick reconnection after grid
returns to normal condition.
5 s/ Real
0...300 s Quick reconnection delay time. 1 = 1 s
135.16 External trip Signal for external grid monitoring trip. 0 / Real
0 … 1 Signal for external grid monitoring trip. 1 = 1
No. Name/Value Description Def/
FbEq16/32
