100 Parameters
154.32 FBA comm SW ver Shows common program revision of the adapter module
in format axyz, where
a = major revision number,
xy = minor revision numbers.
z = correction letter.
Example: 190A = revision 1.90A.
-/ Data
154.33 FBA appl SW ver Shows application program revision of the adapter
module in format axyz, where
a = major revision number,
xy = minor revision numbers,
z = correction letter.
Example: 190A = revision 1.90A.
-/ Data
155 FBA B data in
Selection of data to be transferred from the inverter to
fieldbus controller through fieldbus adapter B.
Note: 32-bit values require two consecutive parameters.
Whenever a 32-bit value is selected in a data parameter,
the next parameter is automatically reserved.
155.01 FBA data in1 Parameters 155.01…155.12 select data to be
transferred from the inverter to the fieldbus controller
through fieldbus adapter B.
None/ List
None None. 0
CW 16bit Virtual address for 16bit control word. 1
Ref1 16bit Virtual address for 16bit reference 1. 2
Ref2 16bit Virtual address for 16bit reference 2. 3
SW 16bit Virtual address for 16bit status word. 4
Act1 16bit Virtual address for 16bit actual value 1. 5
Act2 16bit Virtual address for 16bit actual value 2. 6
CW 32bit Virtual address for 32bit control word. 7
Ref1 32bit Virtual address for 32bit reference 1. 8
Ref2 32bit Virtual address for 32bit reference 2. 9
SW 32bit Virtual address for 32bit status word. 10
Act1 32bit Virtual address for 32bit actual value 1. 11
Act2 32bit Virtual address for 32bit actual value 2. 12
... ... ...
155.12 FBA data in12 See parameter 155.01 FBA data in1 None/ List
156 FBA B data out
Selection of data to be transferred from fieldbus
controller to the inverter through fieldbus adapter B.
Note: 32-bit values require two consecutive parameters.
Whenever a 32-bit value is selected in a data parameter,
the next parameter is automatically reserved.
156.01 FBA B data out1 Parameters 156.01…156.12 select data to be
transferred from the fieldbus controller to the inverter
through fieldbus adapter B. Transfer speed can be set
with parameter 150.51 FBA B Timelevel sel.
None/ List
None None. 0
CW 16bit Control Word (16 bits) 1
Ref1 16bit Reference Ref1 (16 bits) 2
Ref2 16bit Reference Ref2 (16 bits) 3
CW 32bit Control Word (32 bits) 4
No. Name/Value Description Def/
FbEq16/32
