ABB PVS980-58 User Manual

Parameters 61
Parameter listing
No. Name/Value Description Def/
FbEq16/32
101 Actual values
Basic signals for monitoring the inverter.
All parameters in this group are read-only unless
otherwise noted.
101.01 DC voltage Measured intermediate circuit voltage. - / Real
0.00 … 2000.00 V Intermediate circuit voltage. 1 = 1 V/
100 = 1 V
101.02 Line current Calculated phase current. - / Real
0.00 … 30000.00 A Phase current. 1 = 1 A/
100 = 1 A
101.03 Line current % Calculated phase current in percent of the nominal
current.
- / Real
0.0 … 1000.0 % Phase current in percent of the nominal current. 1 = 1%/
10 = 1%
101.04 Active current Measured active current. - / Real
-30000.00 …
30000.00 A
Active current. 1 = 1 A/
100 = 1 A
101.05 Active current % Active current in percent of the nominal value. - / Real
-1000.0 … 1000.0% Active current in percent of the nominal value. 1 = 1%/
10 = 1%
101.06 Reactive current Reactive phase current. - / Real
-30000.00 …
30000.00 A
Reactive phase current. 1 = 1 A/
100 = 1 A
101.07 Reactive current % Reactive current in percent of the nominal value. - / Real
-1000.0 … 1000.0% Reactive current in percent of the nominal value. 1 = 1%/
10 = 1%
101.08 Frequency Estimated grid frequency.
If parameter 91.1 Bamu enable = ON, then line
frequency is calculated from measured grid voltage.
- / Real
0.00 … 100.00 Hz Grid frequency. 100 = 1 Hz
101.09 Grid voltage Measured mains voltage.
Main voltage is measured when parameter 91.1 Bamu
enable = ON.
- / Real
0.00 … 2000.00 V Mains voltage. 1 = 1 V/
100 = 1 V
101.10 Apparent power Calculated output apparent power. - / Real
-30000.00 …
30000.00 kVA
Output apparent power. 1 = 1 kVA/
100 = 1 kVA
101.11 Apparent power % Calculated output apparent power in percentage of the
nominal value.
- / Real
-1000.0 … 1000.0% Output apparent power in percentage. 1 = 1%/
10 = 1%
101.12 Active power Calculated output active power. - / Real
-30000.00 …
30000.00 kW
Output active power. 1 = 1 kW/
100 = 1 kW
101.13 Active Power % Calculated output active power in percentage of nominal
value.
- / Real
-1000.0 … 1000.0% Output active power in percentage of nominal value. 1 = 1%/
10 = 1%
