ABB PVS980-58 User Manual

66 Parameters
124 Reactive power
reference
Settings for reactive power reference selection,
limitation and ramping.
124.01 User Qref Writes reactive power reference value. The unit is
selected with parameter 124.06 Q power ref type.
- / Real
- Reactive power reference value 1 = 1%/
100 = 1%
124.02 Q power ref selection Selects control signal location for reactive power
reference.
User ref/ List
User ref Value of parameter 124.01 User Qref. 0
AI1 scaled Parameter 112.12 AI1 scaled value. 1
AI2 scaled Parameter 112.22 AI2 scaled value. 2
FB A ref1 Fieldbus adapter A reference 1. 3
FB A ref2 Fieldbus adapter A reference 2. 4
DDCS ctrl ref1 Parameter 103.11 DDCS controller ref 1. 5
DDCS ctrl ref2 Parameter 103.12 DDCS controller ref 2. 6
M/F ref1 Master follower reference 1. 7
M/F ref2 Master follower reference 2. 8
124.03 Qref 1 Shows reactive power reference selected with 124.02 Q
power ref selection.
This parameter is read-only.
- / Real
- Reactive power reference value 1 = 1%
100 = 1 %
124.04 Q ref scale Defines scaling factor for 124.03 Qref 1. 1.00 /Real
-1000.00 … 1000.00 Scaling factor. 1 = 1/
100 = 1
124.05 Qref 2 Shows reactive power reference value (124.03 Qref 1)
after scaling.
This parameter is read-only.
- / Real
-200.00...200.00 % Reactive power reference value. 1 = 1%/
100 = 1%
124.06 Q power ref type Selects reactive power reference type and unit. Qref [%]/
List
Ireact ref [A] Reactive current reference in Amperes. 0
Ireact ref [%] Reactive current reference in % of nominal current. 1
Qref [kVAr] Reactive power reference in kVAr. 2
Qref [%] Reactive power reference in % of nominal power. 3
Phi Reactive power reference angle in degrees
1 = 1 degree.
4
CosPhi Reactive power reference in cosphi 0.9 = 0.9 capacitive. 5
AC volt ref [V] AC voltage reference in Volts. 6
AC volt ref [%] AC voltage reference in % of nominal voltage. 7
Q(x) regulation curve Q(x) regulation curve. 8
124.07 Ireact ref % Shows reactive current reference in percent.
This parameter is read-only.
- / Real
-1000.0 … 1000.0% Reactive current reference in percent. 1 = 1%/
10 = 1%
No. Name/Value Description Def/
FbEq16/32
