Parameters 67
124.08 Ireact ref Shows reactive current reference in Amperes.
This parameter is read-only.
- / Real
- Reactive current reference. 1 = 1 A/
100 = 1 A
124.09 Q power ref % Shows reactive power reference in percent of the
nominal power.
This parameter is read-only.
- / Real
-1000.0 … 1000.0% Reactive power reference in percent. 1 = 1%/
10 = 1%
124.10 Q power ref Shows reactive power reference in kVAr.
This parameter is read-only.
- / Real
- Reactive power reference in kVAr. 1 = 1 kVAr/
10 = 1 kVAr
124.11 Ireact ref max % Defines maximum limit for the reactive current reference
in percent.
120.0%/ Real
0.0 … 200.0% Maximum reactive current reference in percent. 1 = 1%/
10 = 1%
124.12 Ireact ref min % Defines minimum limit for the reactive current reference
in percent.
-120.0%/
Real
-200.0… 0.0% Minimum reactive current reference in percent. 10 = 1%
124.13 Ireact ref lim % Shows the limited output reactive current reference.
This parameter is read-only.
- / Real
-200.0 … 200.0% Limited output reactive current reference, 10 = 1%
124.14 Ireact ref ramp up Defines reactive current ramp up time from zero to
nominal current.
1000 ms /
Real
0 … 60000 ms Reactive current ramp up time in milliseconds. 1 = 1 ms
124.15 Ireact ref ramp down Defines reactive current ramp down time from nominal
current to zero.
1000 ms /
Real
0 … 60000 ms Reactive current ramp down time in milliseconds. 1 = 1 ms
124.16 Ireact ref out % Shows percent of output reactive current reference for
the controller.
This parameter is read-only.
- / Real
-200.0 … 200.0% Output value of reactive current reference in %. 1 = 1 % /
10 = 1 %
124.17 Ireact ref out Shows output of reactive current reference in Amperes
for the controller.
This parameter is read-only.
- /Real
- Output value of reactive current reference in Amperes. 1 = 1 A/
100 = 1 A
124.18 Q power ref out % Shows output value of reactive power reference in
percent of the nominal power for the controller.
This parameter is read-only.
- /Real
-200.0 … 200.0% Output value of reactive power reference. 1 = 1%/
10 = 1%
124.19 Q power ref out Shows output value of reactive power reference in kVAr
for the controller.
This parameter is read-only.
- / Real
- Output value of reactive power reference. 1 = 1 kVAr/
10 = 1 kVAr
No. Name/Value Description Def/
FbEq16/32
