Parameters 147
b0: Grounding contactor
command
-
b1: Insulation
measurement disable
command
-
b2...15: Reserved -
210.37 Pre-grounding
insulation resistance
Shows the last measured insulation resistance before
grounding.
This parameter is read-only.
- / Real
0.... Ohm 1 = 1 Ohm
211 Temperature
monitoring
Temperature monitoring related parameters.
All parameters in this group are read-only unless
otherwise specified.
211.01 Main air channel
temperature
Shows main air channel temperature. -/ Real
-100.0 … 200.0 °C 10 = 1 °C
211.05 Control board
temperature
Shows control board temperature measured from the
BCU NTC.
-/ Real
-100.0 … 200.0 °C 10 = 1 °C
211.09 AC cabinet M1
temperature
Shows module 1 AC cabinet temperature. -/ Real
-100.0 … 200.0 °C 10 = 1 °C
211.10 AC cabinet M2
temperature
Shows module 2 AC cabinet temperature. -/ Real
-100.0 … 200.0 °C 10 = 1 °C
211.13 LCL cabinet M1
temperature
Shows module 1 LCL cabinet temperature. -/ Real
-100.0 … 200.0 °C 10 = 1 °C
211.14 LCL cabinet M2
temperature
Shows module 2 LCL cabinet temperature. -/ Real
-100.0 … 200.0 °C 10 = 1 °C
211.21 Highest IGBT M1
temperature
Shows module 1 highest IGBT temperature. -/ Real
-100.0 … 200.0 °C 10 = 1 °C
211.22 Highest IGBT M2
temperature
Shows module 2 highest IGBT temperature. -/ Real
-100.0 … 200.0 °C 10 = 1 °C
211.25 M1 IGBT T1
temperature
Shows module 1 IGBT module temperature 1. -/ Real
-100.0 … 200.0 °C 10 = 1 °C
211.26 M1 IGBT T2
temperature
Shows module 1 IGBT module temperature 2. -/ Real
-100.0 … 200.0 °C 10 = 1 °C
211.27 M1 IGBT T3
temperature
Shows module 1 IGBT module temperature 3. -/ Real
-100.0 … 200.0 °C 10 = 1 °C
211.28 M1 IGBT T4
temperature
Shows module 1 IGBT module temperature 4. -/ Real
No. Name/Value Description Def/
FbEq16/32
