76 Parameters
126.33 Hv Rt sec 2 time Defines duration of high voltage tripping curve (Hv Rt)
section 2. If duration is greater than zero, the low
voltage tripping curve (Lv Rt) section is enabled.
400 ms/ Real
0 … 5000 ms High voltage tripping curve section 2 duration. 1 = 1 ms
126.34 Hv Rt sec 3 time Defines duration of high voltage tripping curve (Hv Rt)
section 3. If duration is greater than zero, the low
voltage tripping curve (Lv Rt) section is enabled.
2000 ms/
Real
0 … 5000 ms High voltage tripping curve section 3 duration. 1 = 1 ms
126.37 Hv Rt S1 start U % Defines starting voltage level of section 1. 130%/ Real
0 … 150% Starting voltage level of section 1. 1 = 1%
126.38 Hv Rt S1 end U % Defines final voltage level of section 1. 130%/ Real
0 … 150% Final voltage level of section 1. 1 = 1%
126.39 Hv Rt S2 start U % Defines starting voltage level of section 2. 120%/ Real
0 … 150% Starting voltage level of section 2. 1 = 1%
126.40 Hv Rt S2 end U % Defines final voltage level of section 2. 120%/ Real
0 … 150% Final voltage level of section 2. 1 = 1%
126.41 Hv Rt S3 start U % Defines starting voltage level of section 3. 115%/ Real
0 … 150% Starting voltage level of section 3. 1 = 1%
126.42 Hv Rt S3 end U % Defines final voltage level of section 3. 115%/ Real
0 … 150% Final voltage level of section 3. 1 = 1%
126.45 Lv Rt trip action Sets low voltage tripping curve event type, fault or pure
event. Inverter stops production in both cases. Fault
needs to be manually reset and pure event
automatically resets.
Internal/ List
Internal Inverter trips and returns to normal action automatically. 0
Fault Inverter trips and requires a fault reset. 1
126.46 Hv Rt trip action Sets high voltage tripping curve event type, fault or pure
event. Inverter stops production in both cases. Fault
needs to be manually reset and pure event
automatically resets.
Internal/ List
Internal Inverter trips and returns to normal action automatically. 0
Fault Inverter trips and requires a fault reset. 1
130 Limits
Operation limits of the inverter.
130.01 Limit word 1 Shows active power limitation status.
This parameter is read-only.
0x0000/
Bit list
b0:P reference max
b1: P reference min
b2: User P max Parameter 130.49 User power limit min % is limiting.
b3: User P min
b4: Reserved
b5: Power ramp
gradient
b6: Stop ramp
b7: P(f)
b8: Grid restore ramp
b9: Grid connect ramp
No. Name/Value Description Def/
FbEq16/32
