ABB PVS980-58 User Manual

Parameters 141
205 PLC Extension
Outputs
PLC output signals.
205.01 Spare AO1 PLC CPU module PM564 analog voltage output of
power module 3 cabinet fan control signal.
-/ Real
0...65535 1 = 1
205.02 PLC Relay Outputs 1 PLC CPU unit PM564 relay outputs 1. 0x0000/
Bit list
b0: Green status lamp
b1: Orange status lamp
b2: Red status lamp
b3: Control section
heating
b4: Power section
heating
b5: Spare RO1
b6 … 15 Reserved
205.03 PLC Relay Outputs 2 PLC I/O unit DX571 # 1 relay outputs 2. 0x0000/
Bit list
b0: M1 Charging
contactor command
b1: M1 AC contactor
command
b2: M1 DC contactor
command
b3: M1 AC breaker trip
reset
b4: M1 AC breaker
close command
b5: M1 AC breaker open
command
b6:M1 WFCB fan
disable
b7: #1 Grounding
resistor bypass control
(MGND 21)
b8: M2 Charging contact
command
b9: M2 AC contactor
command
b10: M2 DC contactor
command
b11: M2 AC breaker trip
reset
b12: M2 AC breaker
close command
b13: M2 AC breaker
open command
b14: M2 WFCB fan
disable
No. Name/Value Description Def/
FbEq16/32
