Parameters 77
b10: External P limit
b11: FRT recovery ramp
b12: P(U)
b13: Flat-top
b14: Input current
b15: Grid current
130.02 Limit word 2 Shows reactive power limitation status.
This parameter is read-only.
0x0000/
Bit list
b0: Q ref max Reactive power reference limited by parameter 124.11
Ireact ref max %.
b1: Q ref min Reactive power reference limited by parameter124.12
Ireact ref min %.
b2: Stopping
b3: Reserved
b4: AC overvoltage
protection
b5...b6: Reserved
b7: AC control max
b8: AC control min
b9...b14: Reserved
b15: Grid current
130.04 Limit word 4 Shows current based limitation status.
This parameter is read-only.
0x0000/
Bit list
b0...b1: Reserved
b2: I max user
b3: Iout Temperature
b4: MV Station limit
b5...b6: Reserved
b7: Nominal power
b8 … b15: Reserved
130.05 Limit word 5 Shows temperature based input current limitation status.
This parameter is read-only.
0x0000/
Bit list
b0: Idc CS temperature
b1: Idc PS temperature
b2: Idc IGBT
temperature
b3: Idc LCL temperature
b4: Idc ambient
temperature
b5: Power section 1
b6: Power section 2
b7: Power section 3
b8: Power section 4
b9 … b15: Reserved
No. Name/Value Description Def/
FbEq16/32
