78 Parameters
130.06 Limit word 6 Shows temperature based grid current limitation status.
This parameter is read-only.
0x0000/
Bit list
b0: Iout CS temperature
b1: Iout PS temperature
b2: Iout IGBT
temperature
b3: Iout LCL
temperature
b4: Iout ambient
temperature
b5...b15: Reserved
130.11 Active power limit to grid Shows maximum allowed active power to grid.
This parameter is read-only.
-/ Real
- 1 = 1 kW
130.13 Reactive power limit Shows maximum allowed reactive power.
This parameter is read-only.
-/ Real
- 1 = 1 kVAr
130.48 User power limit max % Defines customer limit for maximum power. 130.0%/ Real
0.0...200.0 % 10 = 1 %
130.51 Power factor limitation Enables power factor limitation function. Disabled/ List
Disabled 0
Enabled 1
130.52 Power factor min
inductive
Sets minimum inductive power factor limit. -0.9/ Real
-1...-0.1 Minimum inductive power factor limit. 1000 = 1
130.53 Power factor min
capacitive
Sets minimum capacitive power factor limit. 0.85/ Real
0.1...1.0 Minimum inductive power factor limit. 1000 = 1
130.54 Power factor Qind
reserve
Sets inductive reactive power when power factor
limitation function is active. This reactive power is
available even when active power is zero.
-100/ Real
-5000...0 Inductive reactive power. 1 = 1
130.55 Power factor Qcap
reserve
Sets capacitive reactive power when power factor
limitation function is active. This reactive power is
available even when active power is zero.
100/ Real
0...5000 Capacitive reactive power. 1 = 1
130.62 P(f) limit type Selects P(f) limiter type. Disabled/
List
Disabled P(f) limiter function is disabled. 0
Free running See Free running P(f) limitation curve (page 37). 1
Incremental See Incremental P(f) limitation curve (page 37). 2
130.63 P(f) corner frequency Defines corner frequency above the nominal frequency
where limitation starts.
0.20 Hz/ Real
0.00...30.00 Hz P(f) corner frequency. 100 = 1 Hz
130.64 P(f) limit gradient Sets limit gradient in percent of corner power per Hz. 40.0%/Hz/
Real
0.5...200.0%/Hz Limit gradient in percent of corner power per Hz. 10 =1%/Hz
No. Name/Value Description Def/
FbEq16/32
