Accu-Chek Mobile User Manual

214
Changing the batteries14
1 Push the battery compartment cover in the direc-
tion of the arrow as far as it will go to unlock it.
You will have to overcome a slight resistance. The
cover is properly unlocked when it slides over this
resistance with a CLICK.
2 Raise the battery compartment cover as illustrated.

Accu-Chek Mobile Specifications

General

Measurement Technology	Photometric
Sample Type	Capillary whole blood
Sample Size	0.3 µL
Test Time	5 seconds
Battery Type	2 AAA batteries
Connectivity	USB
Dimensions	121 x 63 x 20 mm
Weight	129 g (with batteries)
Display	LCD
Memory Capacity	2000 results
Measuring Range	0.6 - 33.3 mmol/L
Operating Temperature	10 - 40°C
Operating Humidity	10 to 90% RH
Hematocrit Range	20 to 70%
Test Strip Technology	No test strips required (uses a test cassette)
