Accu-Chek Mobile User Manual

50
Initial steps before testing2
1 With the meter off, press and hold the On/Off
button
until the meter turns on (longer than
2 seconds).
When you turn on the meter for the rst time, the
language selection menu is automatically displayed.
The default language is English US. You can either
select this language or replace it by a different one.

Accu-Chek Mobile Specifications

General

Measurement Technology	Photometric
Sample Type	Capillary whole blood
Sample Size	0.3 µL
Test Time	5 seconds
Battery Type	2 AAA batteries
Connectivity	USB
Dimensions	121 x 63 x 20 mm
Weight	129 g (with batteries)
Display	LCD
Memory Capacity	2000 results
Measuring Range	0.6 - 33.3 mmol/L
Operating Temperature	10 - 40°C
Operating Humidity	10 to 90% RH
Hematocrit Range	20 to 70%
Test Strip Technology	No test strips required (uses a test cassette)
