Accu-Chek Mobile User Manual

51
Initial steps before testing 2
2 Press the or button repeatedly until the
desired language is highlighted.
3 Then press the
button below the display to
select the highlighted language.
The meter will then display the language you just
selected.
4 Conrm this information by pressing the
button (OK).
i
If you selected the wrong language by mistake
you can change this setting later (see Chapter
4.9). However, until you do so, the menu will be
displayed in the language you selected.

Accu-Chek Mobile Specifications

General

Measurement Technology	Photometric
Sample Type	Capillary whole blood
Sample Size	0.3 µL
Test Time	5 seconds
Battery Type	2 AAA batteries
Connectivity	USB
Dimensions	121 x 63 x 20 mm
Weight	129 g (with batteries)
Display	LCD
Memory Capacity	2000 results
Measuring Range	0.6 - 33.3 mmol/L
Operating Temperature	10 - 40°C
Operating Humidity	10 to 90% RH
Hematocrit Range	20 to 70%
Test Strip Technology	No test strips required (uses a test cassette)
