ACO 6236 - Page 26

25
＜Memory＞(2/3)
Items Default Contents
● Mode ：Normal ：Normal：Basic setting
Auto ：Automatic measurement, where the following
items are available.
Start ：Start of power supply ON automatic measuring
system.
（It records on the memory card simultaneously）
● Interval ：Single ：Measuring interval setting
Single ：The measurement starts with
[Start/Stop]
key
and is terminated at Meas.Time selected .
Repeat ：The measurement starts with
[Start/Stop]
key
and is repeated in every Meas.Time selected until
[Start/Stop]
key is pressed.
【When Mode：Auto is selected, the following items can be specified】
● I/O ：OFF ：External output setting
OFF ：Default (Data output is disabled).
ON ：Outputs data for one second when the data
mory mode is active.
● Level ：65dB ：65dB ：Threshold level is registered (when the level
exceeds it, recording starts), within the range
20-130dB at resolution 1dB
● Samp Time ：Meas.Time：Meas.Time：sampled at interval equal to Meas.time.
100ms ：sampled at interval 100ms (0.1s).
200ms ：sampled at interval 200ms (0.2s).
1s ：sampled at interval 1s
Meas.Time is time set with
[Meas.Time]
key (1s～-･･･).
＊ Select 10s or more in L
Atm5
measurement.
● Sta ：Registers the starting time for recording (YY/MM/DD HH/MM/SS)
(Year/Month/Date, date time/minute/second)
● Stp ：Registers the stop time for recording (YY/MM/DD HH/MM/SS)
(Year/Month/Date, date time/minute/second)
Fixed to Mease Time, when when RSR card is installed.
Select to
Mode:Auto
Select to
Mode:Start
<Memory> 2/3
Mode ：Normal
Interval ：Single
<Memory> 2/3
Mode ：Auto
Interval ：Single
I/O ：OFF
Level ： 65dB
Samp Time ：MeasTime
Sta：08/10/10 18:16:00
Stp：08/10/12 20:16:00
<Memory> 2/3
Mode ：Start
Interval ：Repeat
I/O out ：232C
