68
＜ Data Contents ＞
130.0+CR+LF ←First data
130.0+CR+LF
・
・ Total 402 data
130.0+CR+LF ←All pass
130.0+CR+LF ←Over all
+CR+LF ←Brake code
130.0+CR+LF ←Next data
Frequency resolution：Case of frequency span is 20kHz: 50 to 20kHz (50Hz step)
Case of frequency span is 10kHz: 25 to 10kHz (25Hz step)
Case of frequency span is 5kHz: 12.5 to 5kHz (12.5Hz step)
Case of frequency span is 2kHz: 5 to 2kHz (5Hz step)
7)Start/Data collect/Stop
Same as normal measurement. The data becomes the FFT data.
＜ Data Contents ＞ ※Transfer the following FFT data
00/01/05⊔02:15:16⊔F⊔130dB+CR+LF
000h00m10s
000dB⊔Z⊔20kHz⊔020s⊔Hann+CR+LF
Hz⊔LIN⊔Max+CR+LF
50⊔⊔⊔⊔130.0⊔130.0+CR+LF
100⊔⊔⊔130.0⊔130.0+CR+LF
・
・
・
20000⊔130.0⊔130.0+CR+LF
AP⊔130.0⊔130.0+CR+LF
OA⊔130.0⊔130.0+CR+LF
