14.2.9 DESCRIPTION OF THE FUNCTION OF OTHER CONTROL BUTTONS
The button starts/stops course recording.
Information about course recording state.
Automatic setting of
oscilloscope parameters
according to the course
character of input signal.
Fig. 47 – Description of the function of other control buttons (figure applies to version 1.00)
Fig. 48 – Oscilloscope appearance during the setting of parameters after AutoSet function activation (figure applies to version 7.2.4)
