Chap. II - Multi-Diag Motortester

Scope_manual_en-v110.docx — 66 —

Fig. 151 – Oil temperature measurement

5.6 FREQUENCY MEASURING OSCILLOSCOPE

The visualization and control are the same as those of the Multi-Diag Scope oscilloscope without the Motortester,

moreover, the measured signal frequency is displayed in the status bar of the oscilloscope, see Fig. 152.

Signal frequency

Fig. 152 – Frequency measuring oscilloscope

5.7 SPEED ENGINE MEASURING OSCILLOSCOPE

The visualization and control are the same as those of the Multi-Diag Scope oscilloscope without the Motortester,

moreover, engine speed is displayed in the bottom right-hand corner, see Fig. 153.
