Probe grounding
HV semsor N
Ignition sensor N2
(grey color)
Ignition sensor N2
(black color)
Fig. 133 – HV measurement on all cylinders - system with distributor (HV probe type N and double ignition probe type N2)
HV sensor C4
Ignition sensor N2
(grey color)
Ignition sensor N2
(black color)
Fig. 134 – HV measurement on all cylinders - after distributor (HV probe type C4 and double ignition probe type N2)
HV sensor C4
Ignition sensor N2
(grey color)
Ignition sensor N2
(black color)
Fig. 135 – HV measurement on all cylinders - before distributor (HV probe type C4 and double ignition probe type N2)
