6/15
C 406
Advanced Menu
GB 04708 - Edition 03 - March 12
This function allows to calibrate the detector internal gauge.
Leak detection:
Internal Pirani gauge
calibration
Setting
Close the detector inlet with a blank-
off flange. Be sure that the detector
is in hard vacuum test and high
sensitiviy mode( (
C 404).
Limit pressure adjustment
Make sure that the internal pressure
is widely lower than 10
-3
mbar.
Start a cycle: press
The value "Pressure" decreases:
wait the stabilisation of this value
(around 5 minutes) and press on the
key
.
Stop the cycle: press
Make sure that the detector is at
atmospheric pressure.
The value "Pressure" increases:
wait the stabilisation of this value
(around 5 minutes) and press on the
key
.
"Cycle end" function = operator ( C 402).
Input/Output menu
Setting of the RS 232 serial
connection parameters.
adixen Vacuum Products - ASM 310 Operating instructions
