Adixen ASM 310 - Tickets Available; Internal Calibration with an Internal Leak;External Leak

8/15
C 406
Advanced Menu
GB 04708 - Edition 03 - March 12
Tickets available
Ticket Example Printing
Internal
calibration with
an internal leak/
external leak
A
Automatic printing after an internal calibration with an internal/
external leak: refer to E 410
Adjustment
checking with an
internal leak
B
Automatic printing after an adjustment checking with an internal
leak:
refer to
C 406
Test/Cycle
C
Automatic printing at the end of the test.
The Memo function must be activated
C 406
A
Internal calibration with an
internal leak/external leak
DATE:Jan/08/2007 TIME:01:34:41
ASM310 CALIBRATION gas: He
unit: mbar.l/sec
CALIBRATED LEAK PARAMETERS:
location: internal/external
value: 1.5E-07
unit: mbar.l/sec
calibration year: 2005
loss per year (%): 06.00
calibration temperature (C): 20
temperature coefficient (%/C): 3.00
TARGET PARAMETERS:
current internal temperature (C): 32
target value: 1.9E-07
ELECTRONIC ZERO:
done: yes
PEAK ADJUSTMENT :
dac_ref.=1162
vacc_ref.=141.8
dac_peak.=1179
vacc_peak.=141.8 yes
SIGNAL RECORDS (no calibrated):
global: 3.5E-07
background: 1.1E-10
CALIBRATION INFORMATIONS:
total time(sec): 75
result: COMPLETED
CURRENT ASM310 CALIBRATION:
DATE:Jan/08/2007 TIME:01:34:41
Fil:1 Ie=0.6 Vac=140.6
Coef_cal:00.54
adixen Vacuum Products - ASM 310 Operating instructions
