4/6
B 112
Product labelling
GB 04701 - Edition 01 - November 12
Located on the detector, this label indicates that the product
lifting must:
be made from the handling points identified with this label
(rings, handles, …),
respect the handling rules book considering its weight and
dimensions.
See Operating Instructions for more details.
Don’t move the leak detector in operation in all positions.
Exhaust port: not to be blocked.
Product drained before leaving factory: fill the primary pump
with oil before running.
NOTICE
PUMP IS SHIPPED WITHOUT
OIL INSTALLED
consult maintenance manual
CAUTION
ATTENTION
POMPE LIVREE SANS HUILE
A L’INTERIEUR
consulter le manuel d’utilisation
ATTENTION
RESTRICTED LIFTING
PLEASE SEE THE
OPERATING INSTRUCTIONS
EXHAUST PORT
DO NOT BLOCK
TRANSPORT OF THE LEAK DETECTOR IN OPERATION
NO
OK
See Operating Instructions
Axis of high vacuum pump
adixen Vacuum Products - ASM 310 Operating instructions
