C 300
Graphic display
1
Measure Exact measure of one point only possible on a recorded plotting.
1 - Select the point
2 -
3 - Exact display of the selected point value
Inlet pressure and
He signal scales
modification
•To have the exact values of all the recoverable measures under any
spreadsheets, save the recorded plotting in .txt file.
1 Inlet pressure or He signal display selection
2 Measure moment regard to recording beginning
3 Mark indicating the measured point
4 Tracer gas signal value (in red) or inlet pressure (in blue) display
5 Navigation between next/previous recorded points
2
3
5
1
4
