Adixen ASM 310 - Locking Clamp; Bombing Chambers; Inlet Filters

8/16
A 400
Accessories
GB 03329 - Edition 06 - February 12
C7
Locking clamp
DN 40 KF
Part number: 118801
Like classical clamp, the locking clamp allows to fix an accessory:
however, you must use a special tool delivered with to open/close
the clamp.
Fixing ring detail Special tool use
Model DN Flange Part No
Bombing chamber 10 bars
(Ø 150 - L 200 - Vol.: 3.5 l)
- 786396
Bombing chamber 25 bars
(Ø 150 - L 200 - Vol.: 6.4 l)
- 786397
C8
Bombing chambers
C9
Inlet filters
Complete inlet filters
Model DN Flange Part No
20 μm inlet filter
20 μm inlet filter
20 μm inlet filter
5 μm inlet filter
5 μm inlet filter
5 μm inlet filter
25/25
40/40
40/25
25/25
40/40
40/25
105841
105842
105843
105844
105845
105846
adixen Vacuum Products - ASM 310 Operating instructions
