A 500
Technical characteristics
GB 03312 - Edition 03 - February 12
Set points adjustments: 85 dB modulated and adjustable audio signal
Hard vacuum Audio signal set point
Adjustable throughout the entire measuring range
Sniffing Audio set point
Adjustable throughout the entire measuring range
Start-up time (at 20 °C)
Without auto-calibration
< 2 min ± 10 %
With auto-calibration
< 3 min 30 s ± 10 %
Time to reach test mode:
inlet port
blanked-off
connected to
1.6 l volume
connected to
46 l volume
Gross Leak test mode 2 s < 25 s < 10 min
Normal test mode
4 s < 35 s < 20 min
High Sensitivity test mode
5 s < 55 s < 100 min
Miscellaneous:
Power voltage
90 - 240 V
±
10%
Power frequency 50/60 Hz single phase
Power consumption (maximum) 300 VA
Start-up temperature 10 to 40 °C
Ambient operating temperature 10 to 40 °C
Storage temperature - 25 to 70 °C
Noise level (at 1 meter; audio alarm not operational, stand-by mode,
after 1/2 h of use)
< 48 dBA
House protection level IP 20
Inlet
DN 25 ISO-KF
Maxi couple to apply on the inlet part (any direction) 5 n.m
Humidity max. (at 40 °C) 95 %
Weight
< 48 lbs
Maximum weight of the tested part 5 kg / 11 lb
