Part Number Quantity Description Notes
Ethernet Serial
GC2-EK-POE 1 GNSS Compass Ethernet
Variant
GNSS Compass Ethernet variant
Power over Ethernet interface
Supports GPS, GLONASS,
Galileo & BeiDou constellation
L1/L2 10mm RTK
Supports DGPS and SBAS
Does not support L band
GC2-EK-SER 1 GNSS Compass Serial
Variant
GNSS Compass Serial variant
RS422/RS232 and CAN interfaces
Supports GPS, GLONASS,
Galileo & BeiDou constellation
L1/L2 10mm RTK
Supports DGPS and SBAS
Does not support L band
CABLE-FTDI 1 RS232/422 Adaptor to
USB
FTDI USB to RS232 / RS422
(selectable) 1 metre cable
SUPPLY-24V 1 1 24 VDCpower supply 100-240 V AC Mains to 24 V DC
Power Supply (DC jack)
Includes 2-pin plug types A/C/G/I
GC-POE-
CABLE-20M
1 20m Ethernet cable for
GNSS Compass
20m CAT5e Ethernet cable with
RJ45
Compatible with Ethernet units
only (GC2-POE)
IP67 environmentally sealed
connector
See Ethernet Connection for full
details
GC-SER-
BREAK-20M
1 20m serial breakout cable
for GNSS Compass
20m cable to DB9 connectors
Compatible with serial units only
(GC2-SER)
IP67 environmentally sealed
connector
See Serial Connection for full
details
POE-
INJECTOR-
1 DCPOEInjector 24V DC PoE Injector
25W 802.3at Type 2 "PoE+"
