6 Installing GNSS Compass
To install and quickly get started with GNSS Compass, follow the instructions provided in the 6.1 Installation
Checklist
Additional information related to installing GNSS Compass is provided in the following sections:
See For
6.2 Mounting
GNSS Compass
Guidelines on selecting the mounting location for the unit.
6.3 Mounting
Alignment
Guidelines on setting the alignment with respect to the vehicle and
antennas.
6.4 Networking Information about changing GNSS Compass to a fixed IPaddress
system after establishing a connection.
6.5 Vibration Steps to mitigate the adverse effects of vibration on the per-
formance.
Table 17: Additional Information
Note: For ordering an evaluation kit, a standalone kit or accessories for GNSS Compass, see 4 Part
Numbers and Ordering.
6.1 Installation Checklist
The GNSS Compass is designed to be plug and play such that it does not normally require any customer
configuration. Typical installations utilising NMEA 0183 or NMEA 2000 will work out of the box.
6.1.1 Connection Options
The cables available from Advanced Navigation feature a connector with a locking nut and o-ring that are
waterproof and dirtproof to the IP67 standard as well as resistant to shock and vibration. The environmental
protection only applies when the connector is locked by pushing in and rotating the nut clockwise until it clicks,
see Figure 8: Connector locking.
v2.0 Page 20 04 Nov 2021
GNSS Compass Reference Manual • Installing GNSS Compass
