10.3.8 IP Configuration Packet

IP Configuration Packet

Packet ID 11

Length 30

Read / Write Read / Write

Field # Bytes Offset Data Type Size Description

1 0 u8 1 Permanent

2 1 u8 1 10.3.8.1 DHCP Mode

3 2 u32 4 IP Address

4 6 u32 4 IP Netmask

5 10 u32 4 IP Gateway

6 14 u32 4 DNS Server

7 18 u32 4 GNSS Compass Serial number part 1

8 22 u32 4 GNSS Compass Serial number part 2

9 26 u32 4 GNSS Compass Serial number part 3

Table 41: IP Configuration Packet

10.3.8.1 DHCP Mode

Bit Description

0 DHCP Enabled

1-7 Reserved (set to zero)

Table 42: DHCP Mode
