5 Specifications
Review the following specifications for GNSS Compass Ethernet:
l
5.1 Navigation Specifications
l
5.2 Hardware Specifications
l
5.3 Communication Specifications
l
5.4 Electrical Specifications
l
NMEA 2000 Drop Cable
l
Ethernet Connection
l
Serial Connection
l
5.5 Certification
5.1 Navigation Specifications
Specification Value
Horizontal Position Accuracy 1.5 m
Vertical PositionAccuracy 2.0 m
Horizontal Position Accuracy (with RTK) 0.01 m
Vertical Position Accuracy (with RTK) 0.015 m
Velocity Accuracy 0.05 m/s
Roll & Pitch Accuracy 0.4 °
Heading Accuracy with Dual GNSS 0.2 °
Heave Accuracy (whichever is greater) 5 % or 0.05 m
Rotation Range Unlimited
HotStart Time (orientation) 1 s
Internal FilterRate 200 Hz
Output Data Rate 200 Hz
Table 8: GNSS Compass Navigation Specifications
5.1.1 GNSS Specifications
Specification Value
Model Advanced Navigation Aries GC2
Supported Navigation Systems GPS L1, L2
GLONASS L1, L2
Galileo E1, E5b
BeiDou B1, B2
Supported SBAS Systems WAAS
