Specification Value
EGNOS
MSAS
GAGAN
QZSS
Update Rate 8 Hz
Hot Start First Fix 6 s
Cold Start First Fix 30 s
Heading Fix (after valid position) 10 s
Acceleration Limit 4 g
Table 9: GNSS Specifications
5.2 Hardware Specifications
5.2.1 Ethernet Variant
Specification Value
Power Input Power over Ethernet (PoE) 802.3af or 802.3at
Power Consumption 1.3 W
Operating Temperature -40 °C to 85 °C
Environmental Protection IP67
Shock Limit 75 g 11 ms
Dimensions (length x width x height) 672 mm x 190 mm x 73.9 mm
Weight 1450 grams
Table 10: Hardware Specifications for GNSS Compass Ethernet
5.2.2 Serial Variant
Specification Value
Power Input 9 to 36 V
Input Protection -40 to 60 V
Power Consumption 1.4 W
Operating Temperature -40 °C to 85 °C
Environmental Protection IP67
Shock Limit 75 g 11 ms
Dimensions (length x width x height) 672 mm x 190 mm x 73.9 mm
Weight 1450 grams
Table 11: Hardware Specifications for GNSS CompassSerial
