10 Advanced Navigation Packet Protocol
The Advanced Navigation Packet Protocol (ANPP) is a binary protocol designed with high error checking, high
efficiency and safe design practices. It has a well defined specification and is very flexible. It is used across all
Advanced Navigation products. A packet type can be identified by its unique Packet ID. For more information
about packets, see 10.1 AboutPackets.
The following packet types are available:
l
10.3 System Packets - These packets have ID values of less than 20.
l
10.4 State Packets - These packets have IDvalues between 20 and 179.
l
10.5 Configuration Packets - These packets have IDs greater than 179.
The following table lists Advanced Navigation packets by type.
Packet
ID
Name Length R/W
System Packets
0 10.3.1 Acknowledge Packet 4 R
1 10.3.2 Request Packet - W
2 10.3.3 Boot Mode Packet 1 R/W
3 10.3.4 Device Information
Packet
24 R
4 10.3.5 Restore Factory Set-
tings Packet
4 W
5 10.3.6 Reset Packet 4 W
10 10.3.7 Serial Port
Passthrough Packet
- R/W
11 10.3.8 IP Configuration
Packet
30 R/W
Packet
ID
Name Length R/W
State Packets
20 10.4.1 System
State Packet
100 R
21 10.4.2 Unix Time
Packet
8 R
22 10.4.3 Formatted
Time Packet
14 R
23 10.4.4 Status
Packet
4 R
24 10.4.5 Position
Standard Devi-
ation Packet
12 R
