ACCEPTANCE TESTING
7-64
Table 7-42 Function generator output tests
Mod. oscillator
frequency (Hz)
Response
level min.
(dB)
Result Response
level max.
(dB)
Result (%)
10
−1
_______ +1
−
20
−1
_______ +1
−
50
−1
_______ +1
−
100
−1
_______ +1
−
200
−1
_______ +1
−
500
−1
_______ +1
−
1000
−1
reference
−
_______
2000
−1
_______ +1
−
5000
−1
_______ +1
−
10000
−1
_______ +1
−
20000
−1
_______ +1
−
50000
−1
_______ +1
−
100000
−1
_______ +1
−
Table 7-43 Function generator level accuracy
RF level (mV) RF level
min. (mV)
Result RF level
max. (mV)
4000 3795 _______ 4205
2000 1895 _______ 2105
1000 945 _______ 1055
500 470 _______ 530
200 185 _______ 215
100 90 _______ 110
50 42.5 _______ 57.5
20 14 _______ 26
10 4.5 _______ 15.5
Table 7-44 External frequency standard tests
External signal Locked [9]
1 MHz, 220 mV [ ]
1 MHz, 1.8 V [ ]
10 MHz, 220 mV [ ]
10 MHz, 1.8 V [ ]
