Aeroflex 2023A - Page 222

ACCEPTANCE TESTING
7-65
ACCEPTANCE TEST RESULTS TABLES
OPTION 3
Table 7-45 RF output at −4 dBm
Carrier Frequency
(MHz)
RF Level Min.
(dBm)
Result (dBm) RF Level Max.
(dBm)
0.03
−4.8
_______
−3.2
0.33
−4.8
_______
−3.2
1
−4.8
_______
−3.2
9
−4.8
_______
−3.2
11
−4.8
_______
−3.2
60
−4.8
_______
−3.2
180
−4.8
_______
−3.2
300
−4.8
_______
−3.2
420
−4.8
_______
−3.2
540
−4.8
_______
−3.2
660
−4.8
_______
−3.2
780
−4.8
_______
−3.2
900
−4.8
_______
−3.2
1020
−4.8
_______
−3.2
1140
−4.8
_______
−3.2
1200
−4.8
_______
−3.2
2023B and 2025
1201
−5.2
_______
−2.8
1260
−5.2
_______
−2.8
1380
−5.2
_______
−2.8
1500
−5.2
_______
−2.8
1620
−5.2
_______
−2.8
1740
−5.2
_______
−2.8
1860
−5.2
_______
−2.8
2050
−5.2
_______
−2.8
2025 ONLY
2220
−5.6
_______
−2.4
2340
−5.6
_______
−2.4
2400
−5.6
_______
−2.4
2510
−5.6
_______
−2.4
