14
The New Job utility mode is available for creating
new jobs (setting up a le structure and dening the
ber under test location: Drives, Folders, Jobs, Routes
End Locations, Cables, Test Equipment Location, and
Operators).
The New Job utility menu is accessed from the Main
Menu by tapping the New Job Touchscreen icon or by
pressing the New Job soft key.
If the active job does not exist in the job hierarchy, the
new job creation screen will start with all settings set to
“--”(none) .
In the new job creation screen, the user is allowed to:
– Create a new job and make the newly created job
“Active”.
– Create multiple new Jobs, Routes, or Cables
without closing the screen. Then select one of the
newly created jobs and make it “Active”.
– Add, remove, and modify static lists associated
with each job setting.
To create a New Job:
• Use
arrows to navigate up/down the list of
available parameters/options.
• Use arrows to scroll through the available
parameters/options (if applicable).
• With the desired parameter/option highlighted, press
Select to open a submenu
A
,which allows the user
to perform the following tasks:
– Select one of the existing names
– Create New
B
Folders, Jobs, Routes, Cables, or
Operator Name
– Edit
C
the selected parameter
– Delete
D
the selected parameter
Example: Job Submenu
New Job Utility
New Job Overview
A
B
C
D
To Next Page
